Especificaciones

    Todos los puertos cobre y uplinks SFP+ son Multi-Gigabit 100/1000/2.5G/5G/10G
    Administración de Layer 2 con funciones de Layer 3 Lite
    QoS avanzado, control de ancho de banda y VLANs
    Gestión mediante interfaz web o puerto de consola (Full CLI)
    Static Routing y MSTP
    Garantía de por vida limitada de D-Link después del registro
    Gestión centralizada con puntos de acceso Wi-Fi D-Link con el software gratuito Nuclias Connect

HW Version

B1

Interfaces

10 x SFP+ ports
2 x 100/1000/2.5G/5G/10G
BASE-T)/SFP+ combo ports

Console Port

RJ-45 console port

Port Standard & Functions

IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3bz 5Gbps and 2.5Gbps Ethernet Over Copper Twisted Pair Cable
IEEE 802.3an 10GBASE-T 10 Gigabit Ethernet
IEEE 802.3ae 10GbE over fiber
IEEE 802.3z 1000BASE-X
Auto MDI/MDIX support for 100BASE-T/1GBASE-T/2.5GBASE-T/5GBASE-T/10GBASE-T

Network Cables for 10GBASE-T

Cat. 6 (30 m max)
Cat. 6A or Cat. 7 (100 m max)

Media Interface Exchange

Auto MDI/MDIX adjustment for all twisted-pair ports

Switching Capacity

240 Gbps

Maximum Packet Forwarding Rate

178.56 Mpps

Transmission Method

Store-and-forward

MAC Address Table

Up to 32,000 entries per device

AC Input

100 to 240 VAC

Maximum Power Consumption

27.4 W

Standby Power Consumption

11.2 W

Operating Temperature

-5 to 50 °C (23 to 122 °F)

Storage Temperature

-40 to 70 °C (-40 to 158 °F)

Operating Humidity

0% to 95% non-condensing

Storage Humidity

0% to 95% non-condensing

Dimensions (L x W x H)

440 x 210 x 44 mm

Weight

2.718 kg (5.99 lbs)

Diagnostic LEDs

Link/Activity/Speed (Per 10GBASE-T port)
Link/Activity/Speed (Per 10G SFP+ port)
Power
Console
Fan error

EMI/EMC Certifications

CE, FCC, IC, RCM, VCCI, BSMI

Safety Certifications

cUL, CB, BSMI

L2 Features

• MAC Address Table
• Up to 32K entries
• Static MAC Addresses
• 128
• IGMP Snooping
• IGMP v1/v2 Snooping
• IGMP v3 awareness
• Supports 384 IGMP groups
• Supports at least 128 static multicast addresses
• Per VLAN IGMP Snooping
• Support host-based fast leave
• MLD Snooping
• MLD v1 Snooping
• MLD v2 awareness
• Support 384 groups
• Support 128 static multicast addresses
• Support host-based fast leave
• LLDP
• LLDP-MED
• Spanning Tree Protocol
• 802.1D STP
• 802.1w RSTP
• 802.1s MSTP
• Flow Control
• 802.3x Flow Control
• HOL Blocking Prevention
• Port Mirroring
• One-to-One
• Many-to-One
• Supports Mirroring for Tx/Rx/Both
• 802.3ad Link Aggregation:
• Maximum of 8 groups/8 ports per group
• Jumbo Frame
• Up to 10KB
• Loopback Detection
• ERPS (Ethernet Ring Protection Switching)

VLAN

• 802.1Q VLAN
• Port-based VLAN
• Configurable VID
• 1~4094
• Voice VLAN
• Auto Surveillance VLAN
• Asymmetric VLAN
• 4K VLAN Groups

Quality of Service (QoS)

• 802.1p Priority Queue
• 8 queues per port
• Queue Handling
• Strict
• Weighted Round Robin (WRR)
• Bandwidth Control
• Port-based (Ingress/Egress, min. granularity 64 Kbps)

L3 Features

• IP Interface
• Supports 8 IPv4/v6 interfaces
• ARP
• 768 Static ARP
• Default Route
• IPv6 Neighbor Discovery (ND)
• Static Route
• Max. 64 IPv4 entries
• Max. 64 IPv6 entries


Access Control List (ACL)

• Max. 50 access list
• Max. 256 ACL rules
• ACL based on
• 802.1p priority
• VLAN
• MAC address
• Ether type
• IP address
• DSCP
• Protocol type
• TCP/UDP port number
• IPv6 flow label

Security

• Broadcast/Multicast/Unicast Storm Control
• D-Link Safeguard Engine
• DHCP Server Screening
• Port Security
• Supports up to 6656 MAC addresses per port
• Duplicate Address Detection
• Traffic Segmentation
• SSL
• Support v1/v2/v3
• Support IPv4/IPv6
• DoS Attack Prevention
• SSH

Operations, Administration, and Management (OAM)
• Cable Diagnostics

Authentication, Authorization, and Accounting (AAA)
• 802.1X Authentication
• Support Dynamic VLAN Assignment
• Identity-driven Policy (VLAN/ACL/QoS) Assignment
• Supports local/RADIUS database
• Supports Port-based access control
• Supports Host-based access control
• Supports EAP, OTP, TLS, TTLS, PEAP
• Support IPv4/IPv6 RADIUS Server
• Guest VLAN
• Authentication for management access

Management

• Web-based GUI
• Full CLI
• Telnet Server
• TFTP Client
• Configurable MDI/MDIX
• SNMP
• Supports v1/v2c/v3
• SNMP Trap
• LLDP
• LLDP-MED
• System Log
• BootP/DHCP Client
• SNTP
• ICMP v6
• IPv4/v6 Dual Stack
• RMON v1
• Trusted Host
• Dual Images
• Dual Configurations
• Debug command

Green V3.0 Technology • Power Saving by:
• LED Shutoff
• System Hibernation
• Port Shutoff

MIB/RFC Standards • RFC2021 RMONv2 MIB
• RFC2460 IPv6
• RFC2461, RFC4861 Neighbor Discovery for IPv6
• RFC2462, RFC4862 IPv6 Stateless Address Auto-configuration (SLAAC)
• RFC2463, RFC4443 ICMPv6
• RFC2464 IPv6 over Ethernet and definition
• RFC2465 IPv6 MIB
• RFC2466 ICMPv6 MIB
• RFC2474, RFC3168, RFC3260 Definition of the DS Field in the IPv4 and IPv6 Headers
• RFC2571 SNMP Framework
• RFC2572 SNMP Message Processing and Dispatching
• RFC2573 SNMP Applications
• RFC2574 User-based Security Model for SNMPv3
• RFC2618 RADIUS Authentication Client MIB
• RFC2668 802.3 MAU MIB
• RFC2674, RFC4363 802.1p MIB
• RFC271, RFC1757, RFC2819 RMON MIB
• RFC2893, RFC4213 IPv4/IPv6 dual stack function
• RFC2925 Ping & TRACEROUTE MIB
• RFC3513, RFC4291 IPv6 Addressing Architecture
• RFC4022 MIB for TCP
• RFC4113 MIB for UDP
• RFC4293 IPv6 SNMP Mgmt Interface MIB
• RFC4884 Extended ICMP to Support Multi-Part Messages
• RFC768 UDP
• RFC792 ICMPv4
• RFC793 TCP
• RFC826 ARP
